PREVOST X3-45 COMMUTER User Manual

SECTION 18: BODY
44
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
11. Install gutter under driver’s window then
compress in order to fix double face self-
adhesive tape.
12. Install 3 clamps and allow curing for 4 hours.
FIGURE 73: CLAMP FOR CURING
FIGURE 74: CLAMPS INSTALLATION
10.1.8 Front Cap
The fiberglass front cap does not need any
maintenance except painting as needed. It is
held in place with adhesive. If ever it has to be
replaced, make an appointment at a Prevost
service center near you. For minor damages,
refer to paragraph 7 “COMMON FIBERGLASS
REPAIR PROCEDURE” and paragraph 8
“COMMON PAINTING PROCEDURE”.

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
