SECTION 03 : FUEL SYSTEM
4
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
1. TORQUE TABLES
1.1 FUEL SYSTEM
03100 03101
FUEL FILTER / PUMP HOUSING – VOLVO D13 ENGINE
No DESCRIPTION TORQUE
1 Fuel filter housing assembly screws 15-21 lb-ft (20-28 Nm)
2 Dosing module mounting screws 7.5 lb-ft (10 Nm)
3 Fuel pump housing mounting screws 6-7 lb-ft (8-9 Nm)
1.2 MISCELLANEOUS TORQUE
MISCELLANEOUS TORQUE
No DESCRIPTION TORQUE
1 Brake pedal potentiometer holding screws 10-20 lb-in (1.13-2.26 Nm)
2 Fuel tank support to frame 55 lb-ft (75 Nm)
3 Air filter cover plastic screws (4) 10-15 lb-ft (14-20 Nm)
4 Steel fuel tank retaining straps 20 lb-ft (27 Nm)

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
