SECTION 18: BODY
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
61
FIGURE 120: CYLINDER BLOCK MOUNTING BOLTS
10.5.2 WCL Cassette Compartment Door
FIGURE 121: WCL CASSETTE COMPARTMENT DOOR
For the removal and installation of the WCL
cassette compartment door skin panel, you will
need:
A drill with drill bits;
Pneumatic hammer tool (Zip Gun);
Razor sharp window scraper or putty knife.
DOOR SKIN PANEL REPLACEMENT
1. Open damaged compartment door and
unfasten rub rail fixing bolts. Remove rub
rail.
2. Mark the position of the door bracket with a
marker for reinstallation.
3. Unfasten bolts (2 each side) and disconnect
cable if necessary in order to remove door
from vehicle.
FIGURE 122: DOOR DISMOUNTING
4. Preferably install the door onto a work
surface where it can be solidly fixed.
5. Refer to SAV10054-67.
Compartment Door Adjustment
6. Refer to baggage compartment door
procedure.
WCL Cassette Door Adjustment
