PREVOST X3-45 COMMUTER User Manual

Mi14-01E Page 32 / 38 Rev: Oct 2021
3 REAR TOW USING NOT APPROVED LIFTING POINTS - FOR
EMERGENCY SITUATIONS ONLY
FOR EMERGENCY SITUATION ONLY
CAUTION
The bus should NOT be lifted and towed from the rear unless an emergency situation occurs or when the
bus has already been damaged and must be moved over a very short distance such as in a parking lot.
Lifting the rear end from the engine cradle or from the side-members located under the engine cradle
support rails should be avoided. Doing so
may cause structural damage (see image further in this
document).
3.1 PRECAUTIONS
In an emergency or if the vehicle has to be
moved over a short distance, the side-
members may be used as lifting point. Try
to lift from the strongest location along
the side-members which is near the rear
subframe vertical member (
Figure 60).
Figure 60: LIFTING POINTS NOT APPROVED FOR REAR-END
TOWING – SIDE-MEMBERS LOCATED UNDER THE ENGINE
CRADLE SUPPORT RAILS

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
