SECTION 05: COOLING SYSTEM
6
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
1.4 MISCELLANEOUS
MISCELLANEOUS
No DESCRIPTION TORQUE
1 Water pump - Back cover to engine 29-41 lb-ft (39-56 Nm)
2 Water pump - body to back cover 15-21 lb-ft (20-28 Nm)
3 Thermostat housing bolts 15-21 lb-ft (20-28 Nm)
4 Electric cooling fan mounting bolts 30 lb-in (3 Nm)
5 Surge tank coolant level sensor (arrow on side must point up) 2 Threads out MAX*
6 Recovery tank coolant level sensor (dot must point down) 1 Threads out MAX**
7 Recovery tank threaded fitting (top of tank) 1 Threads out MAX**
* Add Teflon – PTFE sealant to threads
** Add Loctite MR 5438 Plastic Pipe sealant to threads (DO NOT use PTFE sealant)
