PREVOST X3-45 COMMUTER User Manual

SECTION 18: BODY
52
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
10.4.2 Engine Compartment R. H. Side Door
Adjustment
Engine compartment R. H. side door is adjusted
for proper fit by following the steps below:
1. Loosen door roller support bolts (4)
FIGURE 86: DOOR ROLLER SUPPORTS
2. Loosen balancing arm bolts (2).
FIGURE 87: BALANCING ARM MOUNTING SCREWS
A) SCREWS
B) BELLEVILLE WASHERS
3. Loosen adjustment bolts of the latches (4).
FIGURE 88: LATCH ADJUSTMENT BOLTS
4. Locate the door rubber stoppers (4).
FIGURE 89: RUBBER STOPPERS
5. Make the initial adjustment of the stoppers at
approximately 26 mm (1”) from the mounting
face.
FIGURE 90: STOPPERS INITIAL ADJUSTMENT

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
