SECTION 18: BODY
50
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
3. Using a hammer, adjust the striker pin to
center it in the door latch mechanism.
4. Tighten the striker pin.
5. Check door fit and operation.
10.3.3 Rear Bumper
Remove three bolts on each side holding
bumper to vehicle and remove bumper.
To install bumper, reverse the procedure.
FIGURE 82: REAR BUMPER
10.3.4 Exhaust Aftertreatment System
Access Door
1. Open exhaust aftertreatment system access
door.
2. Loosen the screws holding the panel to
hinge assembly.
3. Adjust the door position according to
distance required between exterior finishing
parts.
4. Tighten the nuts.
5. Check that the door swings freely and closes
properly.
