PREVOST X3-45 COMMUTER User Manual

SECTION 12: BRAKE AND AIR SYSTEM
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
19
9. Apply silicone-based grease to O-rings.
10. Install replacement nut and plastic locking
pins.
11. Install cartridge canister with retaining collar
on dryer base.
12. Using a cross pattern, tighten the four
mounting bolts to 32-35 ft-lbs (43-47 Nm).
MAINTENANCE
Air dryer cartridge
Replace the air dryer desiccant cartridge at the
intervals specified by the Lubrication &
Servicing Schedule in Section 24A.

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
