SECTION 12: BRAKE AND AIR SYSTEM
60
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual Section 12 revised Jan 2021
Antilock Modulator
Make .............................................................................................................................................. Bendix
Model ........................................................................................................................................... M-32QR
Pressure Protection Valve
Make .............................................................................................................................................. Bendix
Model ................................................................................................................................................ PR-4
Nominal closing pressure ................................................................................................ 70 psi (482 kPa)
Prevost number ............................................................................................................................. 641137
Pressure Reducing Valve
Make .............................................................................................................................................. Bendix
Model ................................................................................................................................................ RV-3
Inversion Valve
Make .............................................................................................................................................. Bendix
Model ....................................................................................................................................... TR-2, TR-3
Inline Quick Release Valve
Make .............................................................................................................................................. Bendix
Model ................................................................................................................................................ QR-L
Shuttle-Type Double Check Valve
Make .............................................................................................................................................. Bendix
Model ................................................................................................................................................ DC-4
Air Pressure Regulator
Make .............................................................................................................................................Norgren
Adjustable output range ................................................................................ 0-80/85 psi (0-552/586 kPa)
Air Filter Element
Make .............................................................................................................................................Norgren
Front Axle Brake Chambers
Make ................................................................................................................................... Knorr-Bremse
Type .............................................................................................................................................. 24-inch
Drive Axle Brake Chambers
Make ................................................................................................................................... Knorr-Bremse
Type ..........................................................................................24-inch as service -24-inch as emergency
Tag Axle Brake Chambers
Make ................................................................................................................................... Knorr-Bremse
Type .............................................................................................................................................. 16-inch
Brake Lining (All Axles)
Make ................................................................................................................................... Knorr-Bremse
