SECTION 14: STEERING
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
11
Only unfasten the bolts marked with arrows.
FIGURE 7: POWER STEERING PUMP REMOVAL
8. Install the new power steering pump.
Tighten bolts to specification.
TORQUE: 15-21 lb-ft (20-28 Nm)
NOTE
Use a new gasket.
9. Connect the hydraulic lines to the power
steering pump.
10. Install the fuel pump. Torque-tighten bolts
to specification, refer to "Section 03 Fuel
System".
NOTE
Use a new sealing ring. Check that the fuel
pump drive axle sits correctly in the power
steering pump.
11. Start the engine and let run for 5 minutes.
Make sure that there are no leaks.

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
