PREVOST X3-45 COMMUTER User Manual

SECTION 18: BODY
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
57
FIGURE 108: RADIATOR DOOR DETAILS
NOTE
The strike
r pin must engage at least 13/32”
(10mm). Add spacers between the latch and
the vehicle body to adjust the engagement.
NOTE
There should be no gap between the washer
and the hinge upper and lower halves.
FIGURE 109: TOP HINGE WITH NO GAP

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
