PREVOST X3-45 COMMUTER User Manual

SECTION 18: BODY
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
63
Using a plastic spatula, apply some Sika 221
gray onto the damaged area.
Remove masking tape and protection around
damaged area.
Spray pure water onto Sika. Use a floor sample
to create some texture onto the adhesive.
If possible spray some more water onto the
adhesive to accelerate curing.
Allow drying for at least 2 hours then repaint as
per paragraph: Minor Repair.
• Baggage Compartment Floor Installation
Preparation and Installation
Clean baggage compartment support structure
using anti-silicone.
Glue spacers (790392) about 16 inches apart.
Rear baggage compartment without WCL.

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
