PREVOST X3-45 COMMUTER User Manual

Mi14-01E Page 14 / 38 Rev: Oct 2021
Figure 25: TURN THE RELEASE BOLT (26) IN AN
ANTI-CLOCKWISE DIRECTION UNTIL THE BRAKE IS
RELEASED
CAUTION!
When the towing has been carried out, screw
the release bolt (26) fully into the actuator,
ensuring that the seal in the inner face of the
release bolt head seals against its adjacent
sealing face and tighten to a torque of min. 20
Nm (never exceed 70 Nm).
Figure 26: WHEN THE TOWING HAS BEEN CARRIED
OUT
TURN THE RELEASE BOLT (26) IN A
C
LOCKWISE DIRECTION UNTIL THE BRAKE IS
BACK INTO NORMAL OPERATION

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
