SECTION 23: ACCESSORIES
4
DOB 1300-1556| X3-45 Commuter PA-1648 Maintenance Manual Section 23 revised Nov 2021
WHEEL CHAIN SYSTEM
No DESCRIPTION TORQUE
1 Wheel to ball stud nut 100 lb-ft (136 Nm)
2 Ball stud to arm (clamp) bolts 55 lb-ft (75 Nm)
3 Arm to pneumatic actuator nut 118 lb-ft (160 Nm)
4 Pneumatic actuator to L-bracket 135 lb-ft (183 Nm)
5 L-bracket to support plate 198 lb-ft (268 Nm)
6 Support plate to frame bracket (all) 198 lb-ft (268 Nm)

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
