PREVOST X3-45 COMMUTER User Manual

SECTION 23: ACCESSORIES
DOB 1300-1556| X3-45 Commuter PA-1648 Maintenance Manual Section 23 revised Nov 2021
15
FIGURE 26: LIFT UP THE FRONT SIDE OF THE
CASSETTE
Keep sliding out the cassette until the rear
rollers get to stoppers. Install jacks on the rear
side of the cassette. Lift up the rear side until the
rear rollers clear the stoppers.
FIGURE 27: DROP THE REAR SIDE ON RAILS
Reinstall the control box with the screws (4).
FIGURE 28: CONTROL BOX DISMOUNTING
Slide out completely the wheelchair lift cassette.
FIGURE 29: MOVE OUT THE CASSETTE

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
