PREVOST X3-45 COMMUTER User Manual

SECTION 04 : EXHAUST AND AFTERTREATMENT
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual Section 04 revised March 2021
5
TORQUE SPECIFICATIONS
No DESCRIPTION TORQUE
12
SCR tank strap bolts 30-37 lb-ft (41-50 Nm)
13
NOx sensor 2 (outlet) 30-44 lb-ft (41-60 Nm)
14
Module mounting bolts 5.9-8.8 lb-ft (8-11.93 Nm)
15
SCR tank particulate matter sensor 33-40.5 lb-ft (45-55 Nm)
16
SCR tank temperature sensor (T4) 30-37 lb-ft (41-50 Nm)*
* Use Permatex 454G anti-seize lubricant or Loctite 76764 silver grade anti-seize

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
