FCU Board
D0C5/D0C6/D0C4/D0AP FAX UNIT 14 SM
8. Remove the FCU [A].
9. Attach the jumper [A] on the removed FCU board [B]. The jumper comes with the new FCU
board.
10. Change the position of the battery jumper [A] on the new FCU board [B].
If the battery jumper is not in the correct position, SC820 will occur.
