Bit Switches – 1
SM 59 D0C5/D0C6/D0C4/D0AP FAX UNIT
(D0C5/D0C6
/D0C4/D0AP)
No Function Comments
0
to
7
LS RX memory
capacity threshold
setting
00-FF (0-1020 Kbyte:
Hex)
Sets the value to x4KB. When the amount of available memory
drops below this setting, RX documents are printed to conserve
memory.
Initial setting 0x80 (512 KB)
NOTE: If a customer wants available memory size to be larger,
decrease this threshold
System Switch 1B - Not used (do not change these settings)
System Switch 1C - Not used (do not change these settings)
System Switch 1D (SP No. 1-101-030)
No Function Comments
0 RTI/CSI/CPS code
display
0: Enable
1: Disable
0: RTI, CSI, CPS codes are displayed on the top line of the LCD
panel during communication.
1: Codes are switched off (no display)
1-7 Not used Do not change these settings.
System Switch 1E (SP No. 1-101-031)
No Function Comments
0 Communication after the
Journal data storage area has
become full
0: Impossible
1: Possible
0: When this switch is on and the journal history becomes
full the next report prints. If the journal history is not
deleted, the next transmission cannot be received. This
prevents overwriting communication records before the
machine can print them.
1: If the buffer memory of the communication records for
the Journal is full, fax communications are still possible. But
the machine will overwrite the oldest communication
records.
• This setting is effective only when Automatic
Journal printout is enabled but the machine
cannot print the report (e.g., no paper).
1* Action when the SAF memory
has become full during
scanning
0: The current page is erased.
1: The entire file is erased.
0: If the SAF memory becomes full during scanning for a
memory transmission, the successfully scanned pages are
transmitted.
1: If the SAF memory becomes full during scanning for a
memory transmission, the file is erased and no pages are
To Next Page
