GC-2010 Plus
12 Injection Port
12.1Introduction
Q Types of injection ports described
There are five types of injection system available for gas Chromatography.
・ Split injection system
・ Splitless injection system
・ Direct injection system (option)
・ On-column injection system (option)
・ Programmed temperature vaporization injection system (option)
In this manual, only the split, splitless and direct injection system are described.
For other systems, refer to the User’s manual for each optional unit.
Q Injection system and injection port
Injection system Injection port Type of insert
Split injection system
Split/spitless injection port
Glass insert for split
Splitless injection system Glass insert for splitless/WBI
Direct injection system Direct injection port Glass insert for splitless/WBI
On-column injection system
On-column injection port
Adapter for on-column
Programmed temperature
vaporization injection system
Glass insert for PTV

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
