Shimadzu GC-2010 Plus User Manual

4 Installing the column
4.3
4.
49
GC-2010 Plus
4.3Installing the column hanger
Insert the column hanger into hanger slots inside the column oven as shown.
The hanger is a standard accessory.
Squeeze the top of the hanger in order to insert in the slots.
When one hanger is installed, insert it in the back slots. Install two hangers in both the front and
back slots. The second hanger is optional.
Fig. 4.3.1
Column hanger

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
