14 Diagnosis
14.1 Standard Diagnosis
179
GC-2010 Plus
14.1.5 Starting the diagnosis
Press [Start Diag] (PF menu) from the standard diagnosis main screen shown in Fig. 14.1.1
to start diagnosis and to display the screen shown in Fig. 14.1.3.
14.1.6 PF menu
Fig. 14.1.3   Starting the Diagnosis
PF menu Description
Reference
section
Stop Diag
Stops the diagnosis.
If the program is stopped, items not yet executed are canceled.
14.1.7
Reset
Before stariting the IC diagnosis, the message “Reset IC will be checked.
Press PF2 key.” appears. Press [Reset] (PF menu) to check whether reset
IC is functioning normally.
――
