Shimadzu GC-2010 Plus User Manual

15 Optional Devices
15.2
15.
205
GC-2010 Plus
15.2Setting AUX Temperature
Temperature controller used for parts other than the column oven, injection port, and detector
can be set.
15.2.1 Screen description
When an optional device such as heater is installed, press the [OPTION] key to display the
screen shown in Fig. 15.2.1. If a different screen appears, press the [OPTION] key again or
[NEXT] (PF menu) to display the correct screen.
The screen toggles among AOC parameters → AUX temperature → AUX APC → CRG
screens in this order.
15.2.2 Parameter list
TEMPERATURE SETTING VALUE
Range: 0.0 − 450.0 °C, Default: 25.0 °C
15.2.3 PF menu
Fig. 15.2.1 Main screen to set AUX temperature
PF menu Description
Reference
section
Print Prints each temperature through a Chromatopac. 17.1
NEXT
Toggles the screen among AOC parameters → AUX temperature → AUX
APC → CRG screens in this order.
――
On/Off Displays a sub screen to set a used unit to On. 15.2.4

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
