14 Diagnosis
14.2 Log Reading Menu
185
GC-2010 Plus
14.2.4 Analysis log
When “2. ANALYSIS LOG” is selected, the analysis log is displayed. This log records
whether analyses were allowed to finish and whether controls deviated from their set
valves.
(1) Screen description
Select “2. LOG READING MENU” from the [DIAG] key main screen, then select “2.
ANALYSIS LOG” to display the screen shown in Fig. 14.2.3.
25−545 logs are saved. The number of saved logs depends on the size of each log. If
the number of logs exceeds the capacity, existing logs are deleted starting from the
oldest.
NOTE During a temperature program, if the rate of temperature increase is too great, the GC may not be
within the Ready range temporarily. When this occurs, the analysis log shows “Fail”.
NOTE If there are more items than can be displayed on one screen, scroll through the screen using the left
and right arrow keys.
(2) PF menu
Fig. 14.2.3 Analysis log screen
PF menu Description
Reference
section
Clear Log
Deletes all displayed logs.
When [Clear Log] (PF menu) is pressed, the screen changes and the
message “Clear log with PF2” appears. Press [Clear Log] (PF menu) to
clear the log.
――
Print Prints the analysis log to a Chromatopac.
――
