Shimadzu GC-2010 Plus User Manual

16 Special Functions
16.3 Time Program
232
GC-2010 Plus
16.3.5 Time Program parameters
1: “Relay” description
Parameter Description
Relay
1
Detector
Range
Sets range or attenuation for the detector configured in the
analytical line.
Polarity
Changes the polarity between “+” and “-” for TCD configured in
the analytical line.
Current Sets current for the detector configured in the analytical line.
2
Zero Adj
Turns on/off zero adjustment for the detector configured in the
analytical line.
Flame Ignites / Extinguishes the flame.
FTD
Turns on/off voltage feedback to make current constant for FTD
configured in the analytical line.
Detector controller
Turns on/off control of detector configured in the analytical line
during analysis program.
Flow
controller
Splitter Ctrl Opens/closes splitter.
Flow controller On/Off Turn carrier gas, septum purge, detector gas and APC on/off.
High press inj mode Turns high pressure injection mode on/off.
Gas saver Turns gas saver function on/off.
Temperature
DET1, DET2, AUX3, AUX4,
AUX5
Use a time program to change temperature of heated zones,
which cannot be programmed.
Stop
NUMBER
OF TIMES
OF RUN
End of
program
Specify the number of times to execute the GC program. Then,
either the program stops or the next file is executed. If greater
than 2, the choices are “continuous” or “pause at each run.” For
an AOC, select “pause at each run” When “continuous”. is
selected, the program executes continuously at set intervals.
If another program (such as a temperature program) is running
when time program execution time expires, priority is given to
running the program. When the current program finishes, the
time program stops or file is changed to another file.
0: FILE
0−9 Load
Other Set the parameter to input event No..(Refer to “17.4 Event No.”.)
Relay
Relay
Switch point
Event 91,92 V91−92 Point A or B
PRG V93−94 Point A or B
On/Off point Event 1−16 On or Off
AC On/Off
Oven Exhaust Fan On or Off
Cooling Fan On or Off
CRG INJ On or Off
CRG Colum On or Off

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
