GC-2010 Plus
2 Installation
2.1Shipment Verification
1. GC-2010 Plus main body
2. Quick reference (Part Number 221-40805)
3. Instruction manual CD-ROM (Part Number 221-40801-91)
4. Standard accessories
∗ The column hanger is inserted into the support slots in the oven interior.
∗∗Attach the injection port cover to INJ/DET cover in case of manual injection. (Refer to “2.2 Component
description”
.)
∗∗∗ The plate is attached to the back of the gas chromatograph at the time of installation. (Refer to “QRear view”
of
“2.2 Component description”.)
∗∗∗∗ Attach the cable ties to the hydrogen gas line for making a distinction from other gas lines.
5. FID accessories (only for models with FID)
Type Description Part No. Qty'
To o l s
Wrench 6 × 8
086-03003 2
Wrench 10 × 12
086-03011 2
Wrench for Glass insert nut 221-46977 1
Parts
Branch tube 221-72658-91 1
Injection port Column nut 221-16325-01 1
Column nut 221-32705 1
Ferrule adjuster (for SPL) (SPL Column insertion jig) 221-41532-91 1
Column hanger * 221-47159 1
Injection port cover ** 221-43597-01 1
Partition plate*** 221-73257 1
Screw, M4 × 8 ***
020-46547 2
Cable tie (red)**** 072-60606-01 2
Chromatopac signal cable (115V/230V)
221-47251-41/-43 1
G-type blank nut (with 2 pcs) 221-35566-92 1
Consumables
Silicon rubber septum (with 20 pcs) 201-35584 1
Silica wool stuffing (with 2 g) 221-48600 1
Graphite ferrule 0.5, for capillary (with 10 pcs) 221-32126-05 1
Aluminum gaskets (with 100 pcs) 201-35183 1
Glass insert, for split 221-41444-01 1
Glass insert, for splitless 221-48335-01 1
Fluoride rubber O-ring, for glass insert (with 5 pcs) 036-11203-84 1
Description Part No. Qty'
Ferrule adjuster (for FID) 221-41532-92 1
This unit consists of the following parts. Verify that all items are present.
