15 Optional Devices
15.1 Auto Injector Parameters
204
GC-2010 Plus
15.1.10 Auto-sampler carousel and other optional parameters
Select [Sampler] (PF menu) from the AOC main screen to display the sampler screen shown
in Fig. 15.1.4.
Specify the options installed on the AOC, such as sampler carousel.
When AOC1 and AOC2 are selected for the analytical line in “Line configuration” of the
[SET] key, both “USE OF THE SAMPLER” and “USE OF THE SUB AOC” are automatically
set to “Use”.
15.1.11 Parameter list
USE OF THE SAMPLER
Selection: Use/Not Use, Default: Not Use
This item automatically set to “Use” when “USE OF THE SUB AOC” is set to “Use”.
USE OF THE SUB AOC
Selection: Use/Not Use, Default: Not Use
BAR CODE READER
Selection: Use/Not Use, Default: Not Use
Select “Use” to use each optional unit.
15.1.12 PF menu
Fig. 15.1.4 Sampler carousel and other options setup
PF menu Description
Reference
section
Alloc
When “Use of the Sub AOC” is set “Use”, [Alloc](PF menu) is displayed.
For details, refer to “3.4 Division of Sample” in AOC-20 Dual Injection
System User’s Manual.
――

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
