GC-2010 Plus
18 Maintenance and Inspection
18.1Maintenance Parts
The following tables list maintenance parts and their part numbers (P/N). All parts, which are listed in
the sections from 18.1.1 to 18.1.7 are consumables.
Miscellaneous maintenance part are listed in “18.1.8 Miscellaneous.”
18.1.1 Septum
The type of bleeding differs according to the type of septum and bleeding appears on a
chromatogram in different patterns. For high sensitivity analysis, select a septum of which
bleeding does not appear in positions that hinder the peaks of the subject compounds.
18.1.2 O-ring for glass insert
18.1.3 Glass insert
Parts name P/N Purpose
Silicon rubber septa (with 20 pcs) 201-35584 Injection port septa (Up to 350 °C)
Septa for high temperature (with 20 pcs) 221-48398-91 Injection port septa (above 350 °C)
LL long-life septa (with 20 pcs) 221-48972-91 Injection port septa (above 350 °C)
Thermogreen LB-2 (with 10 pcs) 221-35507-01 Injection port septa (Up to 350 °C)
Part name P/N Purpose
Fluoride rubber O-ring (with 5 pcs) 036-11203-84 standard (Up to 450 °C)
Graphite O-ring (for splitless/WBI) (with 4 pcs)
221-47222-91 For high temperature (350 °C to 450 °C)
Graphite O-ring (for split) (with 4 pcs) 221-48393-91 For high temperature (350 °C to 450 °C)
Fluoride rubber O-ring P4 (with 5 pcs) 036-11202-84 For residual solvents analysis kit
Part name P/N Purpose
Glass insert (For split) 221-41444-01 For split injection technique
Glass insert (For splitless) 221-48335-01 For splitless injection and direct injection
technique
Deactivated glass insert (For splitless) 221-48876-03 5 pcs with deactibated wool
Glass insert (For residual solvent analy-
sis kit)
221-38107-01
Silica wool (with 2 g) 201-48600 Packed in glass insert
