18 Maintenance and Inspection
18.1 Maintenance Parts
286
GC-2010 Plus
18.1.4 Graphite ferrule
18.1.5 Capillary column
To select a capillary column, refer to a column manufactuer’s catarog.
18.1.6 Flow controller
18.1.7 Hydrogen flame ionization detector (FID)
18.1.8 Miscellaneous
Part name P/N Purpose
Graphite ferrule G0.5 (with 10 pcs) 221-32126-05 Capillary column installation
(less than 0.5 mm o.d.)
Graphite ferrule G0.8 (with 10 pcs) 221-32126-08 Wide bore carillary column installation
(0.5 mm to 0.8 mm o.d.)
Part name P/N Purpose
Molecular sieve filter 221-34121-94 For removing contamination in carrier
gas
Trap (SPLIT) 221-42559-92 Split flow line trap
Trap (PURGE) 221-42559-92 Septum purge flow line trap
Aluminum gaskets 201-35183 For tubing connections
Part name P/N Purpose
Jet 221-48258-91 Standard Jet for FID, 0.3 mm inner
diameter
Jet, φ0.8
221-49373-91 For water analysis, 0.8 mm inner diameter
FID Collector 221-72322-91
Igniter 221-41847-93 Igniter for FID
Part Name P/N
FPD detector
Filter (S) 221-73354-01
Filter (P) 221-73354-02
Filter (Sn) 221-73354-03
Quartz cylinder 221-46552
FTD detector
FTD collector ASSY 221-45586-91
FTD-2010 collector repair kit 221-49079-91

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
