Shimadzu GC-2010 Plus User Manual

12 Injection Port
12.5 Split/Splitless Injection System
136
GC-2010 Plus
12.5.8 Septum purge
Set the septum purge flow rate. The septum purge removes contamination from the injection
port at the septum.
The septum purge flow rate is set here. In addition, you can create a program to change the
septum purge flow rate during analysis.
12.5.8.1 Screen description
Select [Purge] (PF menu) from the [FLOW] key main screen to display the septum
purge screen shown in Fig. 12.5.13.
Fig. 12.5.13 Septum purge setup screen
A program can contain up to
7 ramps.

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
