14 Diagnosis
14.2 Log Reading Menu
184
GC-2010 Plus
14.2.3 GC Operation log
Select “1. GC OPERATION LOG” to display the system On/Off log and the heater On/Off
log.
(1) Screen description
Select “2. LOG READING MENU” from the [DIAG] key main screen, then select “1. GC
OPERATION LOG”. The screen shown in Fig. 14.2.2 appears.
Up to 50 logs are stored. If the number of logs exceeds 50, existing logs are deleted
starting with the oldest.
NOTE If there are more items than can be displayed on one screen, scroll through the screen using the left
and right arrow keys.
(2) PF menu
Fig. 14.2.2   Operation log screen
PF menu Description
Reference
section
Clear Log
Deletes all displayed logs.
When [Clear Log] (PF menu) is pressed, the screen changes and the
message “Clear log with PF2” appears. Press [Clear Log] (PF menu) to
clear the log.
――
Print Prints the the operation log to a Chromatopac.
――
