Shimadzu GC-2010 Plus User Manual

16 Special Functions
16.2
16.
222
GC-2010 Plus
16.2Batch Schedule
Use the batch schedule to continuously and automatically perform analyses.
A batch is useful for switching methods automatically during the analyses.
NOTE GCsolution uses the batch schedule function to control the GC-2010 Plus. When GCsolution is used,
do not change the settings for batch schedule.
16.2.1 Screen description
Select “2. BATCH” from the [FUNC] key screen, the Batch screen shown in Fig. 16.2.1
appears.
Q AOC status
The AOC status is displayed on the Batch screen..
Fig. 16.2.1 Batch schedule screen
Screen display Description
Inactive AOC is not operating.
Taking vial Auto sampler arm is picking up a vial.
Preparation AOC is operating (before injection).
Rinse AOC is operating (after injection).
Putting vial Auto sampler arm is returning a vial to the
tray.
Wait AOC is waiting for analysis.
The AOC status is displayed.

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
