Shimadzu GC-2010 Plus User Manual

14 Diagnosis
14.2 Log Reading Menu
187
GC-2010 Plus
14.2.5 Parameter log
When “3. PARAMETER LOG” is selected, parameter names and new values are
displayed when parameters are changed. In addition, the direct operation of valves, etc.
are also displayed.
(1) Screen description
Select “2. LOG READING MENU” from the [DIAG] key main screen, then select “3.
PARAMETER LOG”. The screen shown in Fig. 14.2.5 appears.
Up to 50 logs are saved. If the number of logs exceeds 50, existing logs are deleted
starting from the oldest.
NOTE If there are more items than can be displayed on one screen, scroll through the screen using the left
and right arrow keys.
(2) PF menu
Fig. 14.2.5 Parameter log screen
PF menu Description
Reference
section
Clear Log
Deletes all displayed logs.
When [Clear Log] (PF menu) is pressed, the screen changes and the
message “Clear log with PF2” appears. Press [Clear Log] (PF menu) to
clear the log.
――
Print Prints the parameter log to a Chromatopac.
――

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
