Shimadzu GC-2010 Plus User Manual

15 Optional Devices
15.4
15.
211
GC-2010 Plus
15.4Setting the CRG Parameters
The CRG (option) allows temperatures below room temperature to be set. The CRG can be
connected to the column oven or the INJ2.
15.4.1 Screen description
Press the [OPTION] key from the [OPTION] key main screen, or press [NEXT] (PF menu)
until the CRG screen, shown in Fig.15.4.1, appears.
The [NEXT] (PF menu) key toggles among the AOC parameters → AUX temperature →
AUX APC → CRG screens, in that order.
NOTE If the CRG is turned off after a negative temperature valve has been set, the temperature cannot be
achieved, and the GC cannnot become ready. When turning off the CRG, ensure that the temperature
valve is set properly.
To set the time of the CRG for the column over (COL CRG) auto off, refer to
“16.6.11 Other Settings”
in “16.6 GC Configuration”.
Fig. 15.4.1 CRG main screen

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
