5 Basic Key Operation
5.3 Basic Key Operations
59
GC-2010 Plus
5.3.2 Moving the cursor
Use the four keys, [ ], [ ], [ ] and [ ] to move the cursor to an item to be set.
However, for screens with listed items, only the [ ] and [ ] keys may be available to move
the cursor. The [ ] and [ ] keys may perform a different function.
Q Moving the cursor using the [ ], [ ], [] and [] keys
Example: Main screen of the [COL] key
Q Moving the cursor using only the [ ] and [ ] keys
Example: Main screen of the [FLOW] key
Fig. 5.3.2
Fig. 5.3.3
Move the cursor using the
[], [], [ ] and [ ] keys.
Move the cursor to each
parameter using the [ ]
and [ ] keys.
Items marked with “ ” and
” use the [ ] and [ ]
keys to change the selection.
For example, these keys
change the Split mode setting
in the following order:
SPLIT SPLITLESS
DIRECT SPLIT.
