14 Diagnosis
14.1 Standard Diagnosis
180
GC-2010 Plus
14.1.7 Stopping/exiting the diagnosis
Press [Stop Diag] (PF menu) during diagnosis to display the diagnosis stop screen shown in
Fig. 14.1.4.
When the diagnostics are allowed to complete, the total diagnosis results (Test Result) and
the number of abnormalities (Number of NG) are displayed.
14.1.8 PF menu
Fig. 14.1.4   Diagnosis stops
PF menu Description
Reference
section
Details
When the diagnosis is stopped, diagnosis results up to that time are dis-
played.
When the diagnosis ends, the diagnosis results of all items are displayed.
Press [Print] (PF menu) to print out the displayed diagnosis results to a
Chromatopac.
14.1.9
