Shimadzu GC-2010 Plus User Manual

11.1
11.11.
105
GC-2010 Plus
11 Creating an Oven Temperature Program
11.1 [COL] Key Main Screen
11.1.1 Screen description
Press the [COL] key to display the column screen shown in Fig. 11.1.1. The oven temperature
program is set from this screen.
Enter a value other than 0 in the rate field displayed with “END”. Once a valid rate has been
entered, set the temperature (final temp) and time (hold time) for the line.
In addition to the oven temperature program, the equilibration time is set from this screen.
Equilibration time is the length of time allowed for the oven temperature to properly equili-
brate before the system is Ready.
NOTE Press the [COL] key, to move the cursor directly to the initial temperature portion.
This facilitates program edits when only the initial temperature needs to be changed.
Fig. 11.1.1 [COL] key main screen
Up to 20 temperatue increase/
decrease ramps can be set.

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
