Shimadzu GC-2010 Plus User Manual

14 Diagnosis
14.1 Standard Diagnosis
181
GC-2010 Plus
14.1.9 Diagnosis results
Press [Details] (PF menu) from the screen shown in Fig. 14.1.4 once the standard diagnosis
is have stopped or ended; the Test Result screen shown in Fig. 14.1.5 appears.
Press [Details] (PF menu) from the standard diagnosis screen shown in Fig. 14.1.4 to
display the results of the last test since the power was turned on. Once the power is turned
off, the diagnosis results are cleared.
14.1.10 PF menu list
Fig. 14.1.5 Diagnosis results
PF menu Description
Reference
section
Print Prints out the results of the diagnosis to a Chromatopac.
――

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
