14 Diagnosis
14.1 Standard Diagnosis
182
GC-2010 Plus
Q diagnosis results
・ Good : Displayed when the diagnosis result satisfies the requirements.
・ Not Good : Displayed when the diagnosis result does not satisfy the require-
ments.
・ N/T (= Not Tested) : Displayed when the diagnostic test was stopped or when an item
is excluded from the test.
・ N/A (= Not Applicable) : Displayed when diagnostic test is disabled for the item (ignition
test for a TCD, for example).
・ N/S (= Not Selected) : Displayed when the diagnosis were not perfomed on an item
because it has not been configured in an analytical line.
Certain diagnosis items can be performed for components which
have not been configured. For example, for a detector not
configured in any line, Make Up Gas Control is not checked, but
its detector ROM check can be executed.
・ N/I (= Not Installed) : Displayed when the diagnosis item is not installed.
Q Troubleshooting items which are “Not Good”
Diagnosis item Countermeasures
SEPTUM COUNTER
Replace the septum. (Refer to “18.3 Inspection
and Maintenance: Septum”.)
INSERT COUNTER
Replace the glass insert. (Refer to “18.5 Inspection
and Maintenance: Glass Insert”.)
ROOM TEMPERATURE Check the operation range.
ATMOSPHERIC PRESS Check the operation range.
GAS PRIMARY PRESS
Increase supply pressure to the GC.
For example, adjust the regulator.
DETECTOR IGNITION Refer to “19 Troubleshooting”.
ANY OTHER ITEM Contact your Shimadzu representative.
To Next Page
