GC-2010 Plus
8 Setting the Analytical Parameters and File Management
8.1[SET] Key Main Screen
8.1.1 Main screen
Press the [SET] key to display the main screen shown in Fig. 8.1.1 and to make frequently
used parameter settings.
To make changes to the [COL], [FLOW], [INJ], and [DET] parameters, the [customiz] (PF
menu) key is pressed. Changes to these parameters are reflected in the [SET] key main
screen.
The screen shows parameters for the components which make up one analytical flow line
(injection port, detectors, and options). Use the [Line Config] (PF menu) to change the com-
ponents in the flow line.
When the system is turned on, the temperatures are controlled for the components in the
flow line. If the AFC is present, carrier gas is supplied to the injection port specified. If APC is
present, detector gases are supplied to the detector specified. One injection port and up to
two detectors can be included in an analytical flow line. Temperatures are not controlled, and
gases are not supplied, to components which are not part of the analytical flow line.
Fig. 8.1.1 [SET] key main screen
