Shimadzu GC-2010 Plus User Manual

14 Diagnosis
14.1 Standard Diagnosis
178
GC-2010 Plus
DETECTOR IGNITE
Checks that the ignition pulse is normal.
DETECTOR IGNITION
Verifies whether the ignition operation is normally executed.
ECD FREQUENCY
Verifies whether the frequency of the pulse voltage applied to the ECD is below the limit.
CARRIER GAS ROM, DETECTOR GAS ROM, APC ROM
Verifies whether the data saved in the ROM on the flow controller PCB can be read correctly.
CARRIER GAS AD CONVERTER, DETECTOR AD CONVERTER, APC AD CONVERTER
Verifies whether the contents of the A/D converter on the flow controller PCB can be read
correctly.
GAS CONTROL
Checks that the pressure flow rate is normally controlled.
OVER TEMP PROTECTION
Ensure that the overheat protection circuit is normal.
CPU PERIPHERAL
RESET IC
Verifies that the reset circuit works normally.
WATCH DOG TIMER
Ensures that the IC which checks for software problems is functioning normally.
ROM
Checks that the ROM is intact.
RAM
Verifies whether the RAM can be correctly written and read.

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
