Siemens CU240S DP-F Parameter Manual

Parameters
List of Parameters
1-104
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Time stamp to indicate when a fault has occurred.
P2114 (run-time counter) or P2115 (real time clock) are the possible sources of the time stamp.
In case of PROFIdrive Profile 3.1 or higher configuration, P0969 (system run time counter) is used.
Example: The time is taken from P2115 if this parameter has been updated with the real time.
If not, P2114 is used.
If P2038 is set to PROFIdrive or Namur, P0969 is used.
Index: [0] = Recent fault trip --, fault time 1
[1] = Recent fault trip --, fault time 2
[2] = Recent fault trip --, fault time 3
[3] = Recent fault trip --, fault time 4
[4] = Recent fault trip --, fault time 5
[5] = Recent fault trip --, fault time 6
[6] = Recent fault trip --, fault time 7
[7] = Recent fault trip --, fault time 8
[8] = Recent fault trip -1, fault time 1
Note: P2115 can be updated via Starter, DriveMonitor, etc.
Description: Displays drive fault values. It is for service purposes and indicate the type of fault reported.
The values are not documented. They are listed in the code where faults are reported.
Index: [0] = Recent fault trip --, fault value 1
[1] = Recent fault trip --, fault value 2
[2] = Recent fault trip --, fault value 3
[3] = Recent fault trip --, fault value 4
[4] = Recent fault trip --, fault value 5
[5] = Recent fault trip --, fault value 6
[6] = Recent fault trip --, fault value 7
[7] = Recent fault trip --, fault value 8
[8] = Recent fault trip -1, fault value 1
Description: Displays number of faults stored in P0947 (last fault code).
Dependency: Setting 0 resets fault history.
(changing to 0 also resets parameter r0948 - fault time).
r0948[0...63] Fault time / Fault time
CU240S DP
CU240S DP-F
CU240S PN
Access level: 3 P-Group: Messages Data type: Unsigned32
Unit: - Data set: -
r0949[0...63] CO: Fault value / Fault value
Access level: 3 P-Group: Messages Data type: Unsigned32
Unit: - Data set: -
p0952 Total number of faults / Total faults
Access level: 3 P-Group: Messages Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: T
Min Max Factory setting
0 65535 0
