List of Parameters
Parameters
1-287
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Index: [0] = FB data structure version
[1] = FB driver version
[2] = FB type
[3] = Firmware version
[4] = Firmware version detail
[5] = Firmware date (year)
[6] = Firmware date (day/month)
[7] = unused
Description: Displays control word 1 received from Fieldbus.
Note: If P0700 = 6 (Fieldbus) then P0810 must be set to 2090.15 for correct operation.
This will not be cleared automatically when P0700 is no longer equal to 6.
Description: Displays control word 2 received from Fieldbus.
r8890.0...15 BO: Control word 1 from Fieldbus / CtrlWd1 <- FB
CU240S PN Access level: 3 P-Group: Communications Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 ON/OFF1 Yes No -
01 OFF2: Electrical stop No Yes -
02 OFF3: Fast stop No Yes -
03 Pulse enable Yes No -
04 RFG enable Yes No -
05 RFG start Yes No -
06 Setpoint enable Yes No -
07 Fault acknowledge Yes No -
08 JOG right Yes No -
09 JOG left Yes No -
10 Control from PLC Yes No -
11 Reverse (setpoint inversion) Yes No -
13 Motor potentiometer MOP up Yes No -
14 Motor potentiometer MOP down Yes No -
15 CDS Bit 0 (Hand/Auto) Yes No -
r8891.0...15 BO: Control word 2 from Fieldbus / CtrlWd2 <- FB
CU240S PN Access level: 3 P-Group: Communications Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Fixed frequency Bit 0 Yes No -
01 Fixed frequency Bit 1 Yes No -
02 Fixed frequency Bit 2 Yes No -
03 Fixed frequency Bit 3 Yes No -
04 Drive Dataset (DDS) Bit 0 Yes No -
05 Drive Dataset (DDS) Bit 1 Yes No -
08 Enable PID Yes No -
09 Enable DC brake Yes No -
11 Enable Droop Yes No -
12 Torque control Yes No -
13 External fault 1 No Yes -
15 Command Dataset (CDS) Bit 1 Yes No -
