Siemens CU240S DP-F Parameter Manual

Parameters
List of Parameters
1-22
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Displays motor power.
Dependency: Value is displayed in [kW] or [hp] depending on setting for P0100 (operation for Europe / North America).
Description: Displays measured motor temperature.
Description: Displays inverter overload utilization calculated via the I2t model.
The actual I2t value relative to the max. possible I2t value supplies utilization in [%].
If the current exceeds the threshold for P0294 (inverter I2t overload warning), alarm A0505 (inverter I2t) is gener-
ated and the output current of the inverter reduced via P0290 (inverter overload reaction).
If 100 % utilization is exceeded, alarm F0005 (inverter I2t) is tripped.
Example:
Dependency: r0036 > 0:
If the nominal current (see r0207) of the inverter is exceed, utilization will be displayed, otherwise, 0 % utilization is
displayed.
r0032 CO: Act. filtered power / Act fil. power
Access level: 2 P-Group: Closed-loop control Data type: Floating Point
Unit: - Data set: -
Motor
ω, M
M f 2 M Pmech ⋅⋅
π
⋅=⋅ω=
⇒
[Nm] r0031 [1/min]
60
r0022
π 2
1000
1
[kW] r0032 ⋅⋅⋅⋅=
[kW] r0032 0.75 [hp] r0032 ⋅=
r0035[0...2] CO: Act. motor temperature / Act. mot.temp.
Access level: 2 P-Group: Motor Data type: Floating Point
Unit: [°C] Data set: DDS
r0036 CO: Inverter overload utilization / Invert ovl util
Access level: 4 P-Group: Converter Data type: Floating Point
Unit: [%] Data set: -
Normalized output current
t
100 %
Reaction via p0290
Default: "current reduction"
r0207
r0027
p0294 (95 %)
t
i
2
t [%]
r0036
1
0
A0505
t
