List of Parameters
Parameters
1-99
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Defines first source of OFF3 when P0719 = 0 (BICO).
Dependency: If one of the digital inputs is selected for OFF3, the inverter will not run unless the digital input is active.
When Standard Telegram selected (p0700 = 6, p0922 = Standard Telegram), parameter cannot be changed.
Note: OFF3 means quick ramp-down to 0.
OFF3 is low-active, i.e.
0 = Quick ramp-down.
1 = Operating condition.
Description: Defines first source of OFF3 when P0719 = 0 (BICO).
Dependency: If one of the digital inputs is selected for OFF3, the inverter will not run unless the digital input is active.
When Standard Telegram selected (p0700 = 6, p0922 = Standard Telegram), parameter cannot be changed.
Note: OFF3 means quick ramp-down to 0.
OFF3 is low-active, i.e.
0 = Quick ramp-down.
1 = Operating condition.
Description: Defines second source of OFF3.
Dependency: In contrast to P0848 (first source of OFF3), this parameter is always active, independent of P0719 (selection of
command and frequency setpoint).
If one of the digital inputs is selected for OFF3, the inverter will not run unless the digital input is active.
Note: OFF3 means quick ramp-down to 0.
OFF3 is low-active, i.e.
0 = Quick ramp-down.
1 = Operating condition.
p0848[0...2] BI: 1. OFF3 / 1. OFF3
CU240S DP
CU240S DP-F
Access level: 3 P-Group: Commands Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: T
Min Max Factory setting
- - 2090.2
p0848[0...2] BI: 1. OFF3 / 1. OFF3
CU240S PN Access level: 3 P-Group: Commands Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: T
Min Max Factory setting
- - 8890.2
p0849[0...2] BI: 2. OFF3 / 2. OFF3
Access level: 3 P-Group: Commands Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: T
Min Max Factory setting
- - 1
