List of Parameters
Parameters
1-283
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Resets active faults when changed from 0 to 1.
Values: 0: No fault reset
1: Reset fault
Note: See P0947 (last fault code)
Automatically reset to 0.
Description: Defines time after which a fault will be generated (7220) if no telegram is received from the client.
Dependency: Setting 0 = watchdog disabled
Description: Number of parameters on the drive.
Index: [0] = Read only
[1] = Read & write
Description: Reads the power module serial number, which is stored in the control unit. At power up these serial number are ver-
ified, if any swapping of the CU or the PM had been taken place.
Index: [0] = Production site
[1] = Production year after 2000
[2] = Production month
[3] = Production day
[4] = Production number per day
[5] = Type - not used on all drives
Note: The parameter cannot be changed.
p3981 Reset active fault / Reset active fault
Access level: 4 P-Group: Messages Data type: Unsigned16
Quick comm. NO Active: NO Data set: -
Can be changed: T
Min Max Factory setting
0 1 0
p3984 Client telegram off time / Client tel. off ti
Access level: 3 P-Group: Communications Data type: Unsigned16
Quick comm. NO Active: YES Data set: -
Can be changed: T
Min Max Factory setting
100 [ms] 10000 [ms] 1000 [ms]
r3986[0...1] Number of parameters / No. of parameters
Access level: 4 P-Group: - Data type: Unsigned16
Unit: - Data set: -
p7841[0...5] PM serial no hot swap check / PM Serialno
Access level: 3 P-Group: Converter Data type: Unsigned16
Quick comm. NO Active: YES Data set: -
Can be changed: T
Min Max Factory setting
0 65535 0
