Parameters
List of Parameters
1-262
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: P2828 defines input of NOT 1 element, output is P2829.
Dependency: P2801[9] is active level for the NOT element.
Description: Output of NOT 1 element.
Displays not logic of bit defined in P2828.
Dependency: P2801[9] is active level for the NOT element.
Description: P2830 defines input of NOT 2 element, output is P2831.
Dependency: P2801[10] is active level for the NOT element.
Description: Output of NOT 2 element.
Displays not logic of bit defined in P2830.
Dependency: P2801[10] is active level for the NOT element.
p2828 BI: NOT 1 / NOT 1
Access level: 3 P-Group: Technology Data type: Unsigned32
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
- - 0
p2828
r2829
1
CA
AC
01
10
p2800
p2801[9]
Index0
r2829.0 BO: NOT 1 / NOT 1
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
p2830 BI: NOT 2 / NOT 2
Access level: 3 P-Group: Technology Data type: Unsigned32
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
- - 0
r2831.0 BO: NOT 2 / NOT 2
Access level: 3 P-Group: Technology Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Output of BO Yes No -
