List of Parameters
Parameters
1-279
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Sets the relative widths of the rising and falling pulses. The value in P2949 sets the proportion of the
wobble period (determined by P2945) allocated to the rising pulse, the remainder of the time is allocation to the
falling pulse.
A value of 60% in P2949 means that 60% of the wobble period the wobble output will be rising. For the remaining
40% of the wobble period the wobble output will be falling.
Description: Displays the output of the wobble function.
Description: Gives information about actual fault.
p2949 Wobble signal pulse width / Wobble pul width
Access level: 2 P-Group: - Data type: Unsigned16
Quick comm. NO Active: YES Data set: -
Can be changed: T
Min Max Factory setting
0 [%] 100 [%] 50 [%]
r2955 CO: Wobble signal output / Wobble output
Access level: 2 P-Group: Setpoints Data type: Floating Point
Unit: [%] Data set: -
r3113.0...15 CO/BO: Fault Bit Array / Fault Bit Array
Access level: 1 P-Group: Messages Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Inverter error Yes No -
01 Power line failure Yes No -
02 Intermediate circuit power voltage Yes No -
03 Error power electronics Yes No -
04 Convertor over temperature Yes No -
05 Earth leackage Yes No -
06 Motor overload Yes No -
07 Bus fault Yes No -
08 External safety failure Yes No -
09 Fault motor sensor Yes No -
10 Fault internal communication Yes No -
11 Motor current limit Yes No -
12 Supply failure Yes No -
13 Reserved Yes No -
14 Reserved Yes No -
15 Other error Yes No -
