Parameters
List of Parameters
1-278
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Sets the frequency of the wobble signal.
Description: Sets the value for the amplitude of the wobble-signal as a proportion of the present Ramp Function
Generator (RFG) output. The value of P2946 is multiplied by the output value of the RFG then added to RFG out-
put.
For example, if the RFG output is 10Hz, and P2946 has a value of 0.100, the wobble signal amplitude will be 0.100
* 10 = 1Hz. This means that the RFG output will therefore wobble between 9Hz and 11Hz.
Description: Sets the value for decrement step at the end of the positive signal period. The amplitude of the step is
dependant upon the signal amplitude as follows:
Amplitude of signal decrement step = P2947 * P2946
Description: Sets the value for the increment step at the end of the negative signal period.
The amplitude of the increment step is dependant upon the signal amplitude as follows:
Amplitude of signal increment step = P2948 * P2946
p2945 Wobble signal frequency / Wobble sig freq
Access level: 2 P-Group: - Data type: Floating Point
Quick comm. NO Active: YES Data set: -
Can be changed: T
Min Max Factory setting
0.001 [Hz] 10.000 [Hz] 1.000 [Hz]
p2946 Wobble signal amplitude / Wobble sig amp
Access level: 2 P-Group: - Data type: Floating Point
Quick comm. NO Active: YES Data set: -
Can be changed: T
Min Max Factory setting
0.000 [%] 0.200 [%] 0.000 [%]
p2947 Wobble negative pulse jump / Neg. pulse jump
Access level: 2 P-Group: - Data type: Floating Point
Quick comm. NO Active: YES Data set: -
Can be changed: T
Min Max Factory setting
0.000 1.000 0.000
p2948 Wobble positive pulse jump / Pos. pulse jump
Access level: 2 P-Group: - Data type: Floating Point
Quick comm. NO Active: YES Data set: -
Can be changed: T
Min Max Factory setting
0.000 1.000 0.000
