Parameters
List of Parameters
1-32
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Selects source of display for PZD signals.
Index: [0] = 1st PZD signal
[1] = 2nd PZD signal
[2] = 3rd PZD signal
[3] = 4th PZD signal
[4] = 5th PZD signal
[5] = 6th PZD signal
[6] = 7th PZD signal
[7] = 8th PZD signal
[8] = 9th PZD signal
[9] = 10th PZD signal
Description: Displays PZD signals in [%].
Index: [0] = 1st PZD signal
[1] = 2nd PZD signal
[2] = 3rd PZD signal
[3] = 4th PZD signal
[4] = 5th PZD signal
[5] = 6th PZD signal
[6] = 7th PZD signal
[7] = 8th PZD signal
[8] = 9th PZD signal
[9] = 10th PZD signal
Note: r0096 = 100 % corresponds to 4000 hex.
Description: Determines whether power settings are expressed in [kW] or [hp] (e.g. Rated motor power P0307).
The default settings for the rated motor frequency P0310 and maximum frequency P1082 are also set automatically
here, in addition to reference frequency P2000.
Values: 0: Europe [kW], motor base frequency is 50 Hz
1: North America [hp], motor base frequency is 60 Hz
2: North America [kW], motor base frequency is 60 Hz
Dependency: Where:
• Stop drive first (i.e. disable all pulses) before you change this parameter.
• Parameter P0100 can only be changed with P0010 = 1 (Commissioning mode) via the respective interface (e.g.
USS on RS232).
• Changing P0100 resets all rated motor parameters as well as other parameters that depend on the rated motor
parameters (see P0340 - calculation of motor parameters).
p0095[0...9] CI: Display PZD signals / PZD signals
Access level: 3 P-Group: Closed-loop control Data type: Unsigned32
Quick comm. NO Active: NO Data set: -
Can be changed: T
Min Max Factory setting
- - 0
r0096[0...9] PZD signals / PZD signals
Access level: 3 P-Group: Closed-loop control Data type: Floating Point
Unit: [%] Data set: -
p0100 Europe / North America / Europe / Nth Amer.
Access level: 1 P-Group: - Data type: Unsigned16
Quick comm. YES Active: NO Data set: -
Can be changed: C
Min Max Factory setting
0 2 0
