List of Parameters

Parameters

1-261

SINAMICS G120 Control Units CU240S, Edition 05/2007

Description: P2824[0], P2824[1] define inputs of XOR 2 element, output is P2825.

Index: [0] = Binector input 0 (BI 0)

[1] = Binector input 1 (BI 1)

Dependency: P2801[7] is active level for the XOR element.

Description: Output of XOR 2 element.

Displays exclusive-or logic of bits defined in P2824[0], P2824[1].

Dependency: P2801[7] is active level for the XOR element.

Description: P2826[0], P2826[1] define inputs of XOR 3 element, output is P2827.

Index: [0] = Binector input 0 (BI 0)

[1] = Binector input 1 (BI 1)

Dependency: P2801[8] is active level for the XOR element.

Description: Output of XOR 3 element.

Displays exclusive-or logic of bits defined in P2826[0], P2826[1].

Dependency: P2801[8] is active level for the XOR element.

p2824[0...1] BI: XOR 2 / XOR 2

Access level: 3 P-Group: Technology Data type: Unsigned32

Quick comm. NO Active: NO Data set: -

Can be changed: U, T

Min Max Factory setting

- - 0

r2825.0 BO: XOR 2 / XOR 2

Access level: 3 P-Group: Technology Data type: Unsigned16

Unit: - Data set: -

Bit field: Bit Signal name 1 signal 0 signal FP

00 Output of BO Yes No -

p2826[0...1] BI: XOR 3 / XOR 3
